P. 42

HSK-A


            PFK ṛ蝧獊㾼ᣪଌڏ಩

            PFK HIGH SPEED COLLET CHUCK
            WITH ROUND NUT


















               Balancing  /  㵕ଘᤍ         Dimensions  /  疳ੑ秂纈




                    Max.25,000 RPM
                    Or U ≤ 1gmm
       HSK-A   DIN 69893 FORM A    Max.25,000 RPM                          page.147  page.144  page.117   page.149


                    Or U ≤ 1gmm





                                      Range
                                                               Depth L2
                                                                             Nut
                                        ød
                                                                                    Screw
                                                                                             Collet
                                                                                                          Wrench
             Order No.
                                                                                             ᒻ 䄸
                                                            ڏٍ䄸瞱窼ଶ
             懪搳翥蒈
                                    䄸瞱塅瑻
                                                                                                            瞘 ಋ
                                                                            ᣪ ଌ
                                                                                  藲碉ᣪ妟
                                              ød1
                                                                 30~40
                                                        74
                        PFK10-100S  1.75~10.0  27.5  100 L  L1  Tool Clamping  CAP-PFK10S  PFK-M12  SK10-P  PHS-10-TW275
             HSK50A
                        PFK16-100S  2.75~16.0  40  100  74       40~48  CAP-PFK16S  PFK-M12  SK16-P  PHS-20-RO400
                        PFK10-105S  1.75~10.0  27.5  105  79     30~40  CAP-PFK10S  PFK-M12  SK10-P  PHS-10-TW275
             HSK63A
                        PFK16-105S  2.75~16.0  40  105  79       40~48  CAP-PFK16S  PFK-M12  SK16-P  PHS-20-RO400
             Remarks  /  猋戢                                         Applications  /  䛑አ
             • 襑蟴ݳ 3µ P ᒻ䄸   With 3µ P Grade Collet
                                                                     Drilling  Reaming  Endmilling  Tapping
                                                                      槑৿     柖৿      柮獬      硭粤





















       40    PARFAITE TOOL CO., LTD.
