ER ṛ蝧桗ቐᣪଌڏ
ER COLLET CHUCK
WITH HIGH SPEED
BEARING NUT
HSK-E DIN 69893 FORM E HSK-E DIN 69893 FORM E
Balancing / 㵕ଘᤍ Dimensions / 疳ੑ秂纈
Max.30,000 RPM
Or U ≤ 1gmm
Max.30,000 RPM
Or U ≤ 1gmm
page.146 page.144 page.120 page.148
Range Tool Clamping
Order No. ød Depth L2 Nut Screw Collet Wrench
懪搳翥蒈 䄸瞱塅瑻 ød1 L L1 ڏٍ䄸瞱窼ଶ ᣪ ଌ 藲碉ᣪ妟 ᒻ 䄸 瞘 ಋ
ER20-080BR 1.0~13.0 36 80 60 32~41 CAP-ER20BR ER-M14 ER20-HP PHS-ER20B
HSK40E
ER25-080BR 1.0~16.0 43 80 60 35~40 CAP-ER25BR ER-M18 ER25-HP PHS-ER25
ER16-100BR 1.0~10.0 32 100 74 29~58 CAP-ER16BR ER-M11 ER16-HP PHS-ER16B
ER20-100BR 1.0~13.0 36 100 74 32~59 CAP-ER20BR ER-M14 ER20-HP PHS-ER20B
HSK50E
ER25-100BR 1.0~16.0 43 100 74 35~57 CAP-ER25BR ER-M18 ER25-HP PHS-ER25
ER32-100BR 2.0~20.0 51 100 74 41~56 CAP-ER32BR ER-M22 ER32-HP PHS-ER32
Remarks / 猋戢 Applications / 䛑አ
• 襑蟴ݳ 3µ HP ᒻ䄸 With 3µ HP Grade Collet
• 舙襑砇蟴Ӿஞڊᓕ牧藶㷢ᘍ page.145 憒໒蔭
• 舙襑ڊࣳڏ牧藶㷢ᘍ page.26 螡አ藯ก
Drilling Reaming Endmilling Tapping
槑 柖 柮獬 硭粤
51
