COLLET

PFC / HY ᒻ䄸

PFC / HY COLLET

ᒻ䄸 䛑አෝ䔶ێ(PFC)ڏ಩

COLLET APPLY TO PFC
TOOL HOLDER

Ӟ膢ࣳ Ӿஞڊ࿜ࣳ(ࣳୗC)
Normal Type Coolant Through Type
Order No. Precision Class
懪搳翥蒈 羊ੂ缛羷 øD ød øD1 L L1
PFC20 Ӟ膢羷 Normal 20 4,5,6,7,8,9,10,12,14,16 25 51.5 49.5
PFC20-A 羊ੂ羷 A Class 20 4,5,6,7,8,9,10,12,14,16 25 51.5 49.5
PFC20C 羊ੂ羷 A Class 20 4,5,6,7,8,9,10,12,14,16 31 52.5 50.5
PFC32 Ӟ膢羷 Normal 32 6,8,10,12,14,16,18,20,25 37.5 64 61.5
64
PFC32-A 羊ੂ羷 A Class 32 6,8,10,12,14,16,18,20,25 37.5 63.5 61.5
COLLET 懪搳ֺ Order Example: PFC20-8 , PFC20-8A, PFC20C-8
32
60.5
6,8,10,12,14,16,18,20,25
羊ੂ羷 A Class
45
PFC32C
ᒻ䄸 䛑አෝရ瓟(HY)ڏ಩
COLLET
$33/< 72 +< 722/ +2/'(5

Ӟ膢ࣳ Ӿஞڊ࿜ࣳ(ࣳୗC)
Normal Type Coolant Through Type
Order No.
懪搳翥蒈 øD ød øD1 L L1
HY12C 12 3,4,5,6,8 19 47 45
HY20 20 4,5,6,7,8,9,10,12,14,16 25 51.5 49.5
HY20C 20 4,5,6,7,8,9,10,12,14,16 31 52.5 50.5
HY32 32 6,8,10,12,14,16,18,20,25 37.5 64 61.5
HY32C 32 6,8,10,12,14,16,18,20,25 45 63.5 60.5
懪搳ֺ Order Example: HY20-8, HY20C-8
Remarks / 猋戢
• ڏٍຢ䕩獍癩 h6( h6 Tooling Diameter Tolerance)

118 PARFAITE TOOL CO., LTD.
