ISO
TOOL HOLDERS PFK筒夾刀把

PFK COLLET CHUCK

ISO

TOOL PFK Collet Chuck
HOLDERS
• INCLUDING PULL STUD AND BALANCING
• 附拉桿、動平衡

RUN-OUT PRECISION BALANCED GRADE APPLICATION

5µm G2.5
30,000 RPM
or U ≤ 1 gmm

SPECIFICATIONS

拉桿 螺帽 筒夾 扳手A 扳手B
夾持 Pull Stud Nut Collet Wrench Wrench
訂購編號 FIG 範圍 øD L L1
ORDER NO RANGE
ød

ISO20 PFK10-035 26 PI20T-1 PHS-ISO20
1 1.75~10.0 27.5 35
ISO25 PFK10-035 26.2 PI25T-1 CAP-PFK10 SK10P PHS-PFK10 PHS-ISO25
開口扳手25.4
PFK10-060 1 1.75~10.0 27.5
ISO30 60 40.9 PI30T-1 SPANNER 25.4
PFK16-060 2 2.75~16.0 40 CAP-PFK16 SK16P PHS-PFK16 PHS-ISO30
• With 3µ P Grade Collet • 需配合3µ P 筒夾
