SK

FMB ᶎ柮ڏአڏ಩

FMB FACE MILL ARBOR
(獍ګ柮ڏአMetric size҂

Dimensions / 疳ੑ秂纈

SK DIN 69871 page.145 page.145

Order No.
懪搳翥蒈 øD øC1 øC2 L L1 K W وአᣪ妟 M Spacer Ring
Օྊ
FMB22-050 22 48 28 50 18 5 10 M10xP1.5 FMSP-22
FMB22-050S ̣ 22 40 28 50 18 5 10 M10xP1.5 FMSP-22
FMB27-055 27 58 33 55 20 6 12 M12xP1.75 FMSP-27
FMB27-055S ̣ 27 48 33 55 20 6 12 M12xP1.75 FMSP-27
SK40
FMB32-055 32 78 40 55 22 7 14 M16xP2.0 FMSP-32
FMB32-055S ̣ 32 58 40 55 22 7 14 M16xP2.0 FMSP-32
FMB40-060 40 79 50 60 26 8.5 15.9 M20xP2.5 FMSP-40
FMB40-060S ̣ 40 76 50 60 26 8.3 15.9 M20xP2.5 FMSP-40
FMB22-050 22 50 28 50 18 5 10 M10xP1.5 FMSP-22
FMB22-050S ̣ 22 40 28 50 18 5 10 M10xP1.5 FMSP-22
FMB27-055 27 58 33 55 20 6 12 M12xP1.75 FMSP-27
FMB27-055S ̣ 27 48 33 55 20 6 12 M12xP1.75 FMSP-27
SK50
FMB32-055 32 78 40 55 22 7 14 M16xP2.0 FMSP-32
FMB32-055S ̣ 32 58 40 55 22 7 14 M16xP2.0 FMSP-32
FMB40-060 40 89 50 60 26 8.5 15.9 M20xP2.5 FMSP-40
FMB40-060S ̣ 40 76 50 60 26 8.3 15.9 M20xP2.5 FMSP-40
Remarks / 猋戢 Applications / 䛑አ
̣襑蟴ݳ SANDVIK ᶎ柮ڏԏڏ಩憒໒疳ੑ
APPLY TO SANDVIKŇS FACE MILLER.
Face Milling
ᶎ柮

102 PARFAITE TOOL CO., LTD.
